Three Bedroom House Elevation Drawing

1. Front Elevation

• Design Style: Modern with a touch of traditional charm, featuring a combination of materials.
• Materials:
  • Walls: A mix of smooth stucco and natural stone for a sophisticated look.
  • Roof: Hip roof design with overhanging eaves for added character.
• Windows:
  • Large, expansive windows (approximately 2.5m x 1.5m) in the living room and dining area to maximize natural light.
  • Smaller, vertical windows (approximately 1m x 1.2m) in each bedroom for privacy while maintaining light.
• Entrance:
  • A welcoming front porch with a decorative gabled roof, supported by stylish columns.
  • A large front door (approximately 1m x 2.1m) with sidelights for additional illumination.
  • Steps leading up to the porch, possibly with a small seating area.

2. Side Elevation

• Design Features:
  • Symmetrical window placement for all three bedrooms, providing a balanced look.
  • Eaves that extend beyond the walls, offering protection from rain and sun.
• Materials:
  • Consistent with the front elevation, using stucco and stone accents.
• Utility Space:
  • A discreet area for HVAC systems or storage, designed to blend seamlessly with the house exterior.

3. Back Elevation

• Design Elements:
  • Sliding glass doors (approximately 2m x 2.5m) from the living room and dining area leading to a spacious backyard deck or patio.
  • Windows (approximately 1.5m x 1.2m) in the master bedroom for views and natural light.
• Roof Features:
  • Extended roofline over the patio area, providing shade and comfort for outdoor activities.
  • Possible inclusion of a pergola or awning for added outdoor living space.

4. Materials and Colors

• Color Palette: Earthy tones such as taupe, cream, and accents of dark brown for a cohesive and inviting look.
• Finishes:
  • Textured stucco for walls and smooth finish for stone elements.
  • Wood trim for windows and doors to enhance warmth.

5. Overall Aesthetic

• Style: A harmonious blend of modern architecture with traditional influences, creating an inviting and functional family home.
• Functionality: Designed for optimal natural light, ventilation, and outdoor connectivity.

Related Content

• Design Inspiration:

  • Showcase images of various three-bedroom homes to provide visual context and diverse styles.
  • Highlight different architectural influences, such as contemporary, craftsman, or traditional styles.

• Construction Details:

  • Discuss structural elements including foundation types, energy-efficient materials, and roofing options.
  • Importance of proper drainage and landscaping design for aesthetics and functionality.

• Interior Features:

  • Describe the interior layout that complements the elevation, emphasizing open-plan living spaces and bedroom designs.
  • Mention sustainable practices in the construction process, such as using recycled materials and energy-efficient systems.

• 3D Rendering:

  • Provide a 3D model of the elevation to give a realistic view of the house design.
  • Interactive features allowing users to visualize different materials, color schemes, and window configurations.
