Two Bedroom House Elevation Drawing

Two Bedroom House Elevation Drawing

1. Front Elevation

• Design Style: Contemporary with a blend of traditional elements for a welcoming façade.
• Materials:
  • Walls: Combination of textured stucco and wood siding for a modern yet warm appearance.
  • Roof: Gable roof design with a central peak, enhancing architectural interest.
• Windows:
  • Large front windows (approximately 2m x 1.2m) in the living room and bedroom areas for ample natural light.
  • Smaller accent windows (approximately 0.8m x 1m) on either side of the front door.
• Entrance:
  • Covered porch with a stylish front door featuring sidelights for added light.
  • Decorative columns supporting the roof overhang.
  • Steps leading up to the porch, possibly with a small seating area.

2. Side Elevation

• Design Features:
  • Balanced window placement for both bedrooms, providing privacy while allowing for light.
  • Eaves that extend beyond the walls, providing shade and protecting windows from rain.
• Materials:
  • Similar materials as the front elevation with consistent color schemes.
• Utility Space:
  • Area for air conditioning units or other utilities, designed to blend with the exterior.

3. Back Elevation

• Design Elements:
  • Sliding glass doors (approximately 2m x 2m) leading from the living area to the backyard patio, promoting indoor-outdoor living.
  • Windows (approximately 1.2m x 1m) in both bedrooms for additional light and views.
• Roof Features:
  • Extended eaves for shading and protection from the elements.
  • Potential for a small awning or pergola over the patio area.

4. Materials and Colors

• Color Palette: Soft neutrals such as beige, white, and earthy tones for a harmonious look.
• Finishes:
  • Stucco finish on the main walls.
  • Natural wood accents for doors, windows, and siding.

5. Overall Aesthetic

• Style: A blend of modern and classic elements, providing a charming yet contemporary appearance.
• Functionality: Thoughtful design features that enhance natural light and outdoor access.
